10L Lab Ribbon Blender
lab scale Ribbon blender, lab scale Ribbon blender for Spice mixing
Ribbon Blender R&D Lab Model finds its application in a wide array of industries ranging from pharmaceutical, chemical and food industries. It is intricately designed to uniformly mix dry and wet materials which are commonly used in these industries. If you are looking for a compact cGMP compliant and yet comprehensive system that comes with a rigidly fabricated structure, this machine is an apt pick for you.
Our Small Ribbon Blender comes with a fabricated structure motor, mixing drum, gear box and stirrer. The machine offers a perfect sealing arrangement and the discharge slide valve device provides easy unloading. If needed the stirrer can be provided as per your requirements- for instance: ribbon type or paddle type. All contact parts of the machine are manufactured with SS 304/316.
For ensuring accuracy at all times, the process can be monitored through the dust cover this machine comes equipped with. This dust cover keeps you in total control for dusting and contamination prevention purposes. The ribbon blender R&D lab model also features a direct drive arrangement which is way better and more compact than antiquated belt drives with extra dependence on flexible belts and pulley sets to achieve desired speeds and torque ranges.
For more information related to 10 liters ribbon mixer, feel free to get in touch with us.
Salient Features of Small Ribbon Blender
Cantilever model.
Different shape and size bowl can be interchange.
Control panel fitted on same platform.
Contact parts made from SS 316 grade materials.
Machine stand and control panel structure made from SS 304.
Interlocking with safety grill provided hence machine stop in case of grill not on position.
All moving parts like motor and gearbox covered by Stainless Steel 304 cover.
Mirror finish from inner surface and matt finish on outer surfaces.
Speed reduction worm gearbox installed.
Easy to operate and less maintenance requires.
Lab Ribbon Blender Technical Specification
Machine Model ARB – 5
Design type Cantilever design
Design Feature Interchangeable Bowls
Capacity (Gross) 8 Liters approx.
Capacity (Working) 4 Liters approx.
Material Contact Parts SS 316 Materials
Machine Structure SS 304 Materials
Bearing Double Roller Bearing
Drive 0.5 H.P., 1440 RPM, 3 Phase, NFLP
Power Voltage 220 volts, Single Phase, 50 Hertz
Discharge Source Butterfly Valve
Gearbox Reduction type gear, Ration 30:1
Applications of Lab Ribbon Blender
Ribbon Blender can be use for wide array of application span over pharmaceuticals, cosmetics, bulk ingredients, food preservatives, specialty chemical, beverages and lot more. Below are some of the major applications of the equipment:
Pharmaceuticals Application: Bulk Drugs, API and Nutraceuticals
Cosmetics Application: Talcum Powder, Eye shadow, Face powders, Laundry detergents
Chemicals Application: Dyes, Intermediates, Pigments, Pesticides, Fine Chemicals, Rubber Chemicals, Abrasives, Engineered plastic resins, Epoxy resins, Carbon black, Fire retardants, Polyethylene, Chemicals, Gypsum, PVC compounding, Cleaning compounds, Plastic powders
Food Appliactions: Infant formula, Cocoa mix, Instant salad dressing, Cake mixes, Seasonings, Flavorings, Gelatin, Milk Powder, Pet foods, Bakery premixes, Cake mixes, Instant breakfast cereals, Spice blends, Dietary supplements, Instant drink blends, Spices, Dried food products
Agrculture Application: Insecticides, Pesticides, Fertilizers, Pesticides and herbicides, Bird seeds
Other Applications: Handling large Dry and wet powder volume, Crystalline products, Low-viscosity paste and liquid in chemicals
Lab Ribbon Blender Specification
| Model | Gross Volume approx. | Working Volume approx. | Power |
| RM-10 | 10 Liters | 5 Liters | 0.5 H.P. |
| RM-50 | 50 Liters | 20 Liters | 1 H.P. |
| RM-75 | 75 Liters | 50 Liters | 1 H.P. |
| RM-150 | 150 Liters | 100 Liters | 2 H.P. |
| RM-250 | 250 Liters | 150 Liters | 3 H.P. |
| RM-450 | 450 Liters | 300 Liters | 5 H.P. |
| RM-600 | 600 Liters | 450 Liters | 7.5 H.P. |
| RM-1100 | 1100 Liters | 750 Liters | 10 H.P. |
| RM-1500 | 1500 Liters | 1000 Liters | 12.5 H.P. |
| RM-2000 | 2000 Liters | 1250 Liters | 15 H.P. |
| RM-3000 | 3000 Liters | 1875 Liters | 20 H.P. |
| RM-5000 | 5000 Liters | 3000 Liters | 25 H.P. |
| RM-10000 | 10000 Liters | 6000 Liters | 40 H.P. |
* Power voltage can be adjusted as per customer’s domestic power voltage requirements.
* Rights of technical improvements & modification reserved.
* Illustrations & dimensions are shown for information purpose only.
